P25633 INDUSTRIAL ADAPTER 12 VDC 3A 36V UNV
Content
1. SAFETY STANDARD…………………………………………………………….……..................4
2. INPUT FEATURE………………………………………………………………….........................4
3. OUTPUT FEATURE……………………………………………………………….…....................5
4. PROTECTION FEATURE………………………………………………………………................5
5. ENVIRONMENTAL CONDITIIONS…………………………………………..….…….................6
6. EMC STANDARDS………………………………………………….. …........... ..…….................6
7. RELIABILITY AND QUALITY CONTROL………………………………………...….. ...............7
8. DIELECTRIC WITHSTANDING STRENGTH (HI-POT)……………………….……................7
9. INSULATION RESISTANCE……………………………..……………………….…....................7
10. LEAKAGE CURRENT………………………………………..... ……...….................................7
11.MAJOR MEASURE EQUIPMENT…………………………………………….…………............7
12. PRODUCT EXTERNAL VIEW………………………………………….…………………..........8
1. SAFETY STANDARD
The green mode switching power supply shall be certified by the following international regulatory
standards:
Country
Certified Status
Standard
GS
Europe
MEET
EN61347-1，/-2-13
CE
Europe
MEET
EN61347-1，/-2-13
UL
USA
MEET
UL 8750+UL60950
CUL
Canada
MEET
UL 8750+UL60950
-
Europe
MEET
（ Blue Angel）
-
USA
MEET
（Energy start）
2. INPUT FEATURE
2.1 INPUT VOLTAGE RANGE：90Vac to 264Vac
2.2 RATED INPUT VOLTAGE: 100Vac to 240Vac
2.3 INPUT FREQUENCY RANGE: 47Hz to 63Hz
2.4 RATED INPUT FREQUENCY: 50Hz/60Hz
2.5 INPUT CURRENT:0.8A max.&100Vac.
2.6 INRUSH CURRENT: 30A max. at 100-240Vac input for a cold start at 25oC.
2.7 EFFICIENCY: higher than 75% at 100-240Vac input and output full load(1A).
3. OUTPUT FEATURE
12.0VDC
RATED OUTPUT VOLTAGE
SPEC. LIMIT
Min. value
Max. value
Unload output regulation
11.4VDC
12.6VDC
Rated load output voltage
11.4 VDC
12.6 VDC
0.0 A
2.5A
Rated output current
Short-circuit output power
Hiccup mode
hiccup(3W)
Line regulation
≤1%
Load regulation
≤5%
Ripple and Noise
(20MHz Bandwidth 10uF Ele.Cap. & 0.1uF Cer. Cap.)
Transient response
(Output load change from 20% to 80% of full load(2.5A))
≤100 mVp-p.
≤450mV
4. PROTECTION FEATURE
4.1.OVER - CURRENT PROTECTION: The power supply shall be hiccupped and no damage shall
occur when output current reaches to its over-current protection trigger point (set@ Max load
120-300% ). The power supply shall be self - recovery when the fault condition is removed.
4.2 SHORT - CIRCUIT PROTECTION: The power supply shall be hiccupped(input power less than
3W) and no damage shall occur when any output operating in a short circuit condition under any
line condition for an indefinite period of time. The power supply shall be self - recovery when the
fault condition is removed.
4.3 OVER - VOLTAGE PROTECTION: The power supply shall be hiccupped and no damage shall
occur when output current reaches to its over- voltage protection trigger point (set@ Max output
voltage 120-180% ). The power supply shall be self - voltage when the fault condition is removed.
5. ENVIRONMENTAL CONDITIIONS
5.1 OPERATING: The power supply shall be capable of operating continuously in any mode without
performance deterioration in the following environmental conditions.
5.1.1 Ambient Temperature: 0℃～40℃
5.1.2 Relative Humidity: 10%～90%
5.1.3 Vibration: 1.0mm, 10–25Hz, 15 minutes per cycle for each axis (X, Y, Z)
5.2 NON-OPERATING: The power supply shall be capable of withstanding the following
environmental conditions extended periods of time, without sustaining electrical or mechanical
damage and subsequent operational deficiencies
5.2.1 Ambient Temperature: -30℃～70℃
5.2.2 Relative Humidity: 10%～90%
5.2.3 Vibration and Shock :The power supply shall be designed to withstand normal transportation
vibration per MIL–STD-810D, method 514 and procedures X, as it is mounted in the chassis
assembly and packed for shipping.
5.2.4 Drop Test ：Power supply product can in transport process, because the accident
drops into its ground and cement ground( tallest 1.55 Ms)s fall in in proper
order for Mitsubishi six,without sustaining electrical or mechanical damage and
subsequent operational deficiencies
6. EMC STANDARDS
6.1 EMI STANDARDS
The power supply met the radiated and conducted emission requirements requirements for
FCC PART15B CLASS B, EN55015，
7. RELIABILITY AND QUALITY CONTROL
7.1 BURN-IN: The power supply shall under go a minimum of 8 hours Burn-In test under full load at
35℃±5 ℃.
7.2 COMPONENT DERATING: Semiconductor junction temperatures shall not exceed the
manufacturer’s maximum thermal rating.
7.3 MTBF: When the power supply is operating within the limits of this specification the MTBF shall be
at least 50,000 hours at 25℃ (MIL-STD-217F).
8. DIELECTRIC WITHSTANDING STRENGTH (HI-POT)
Primary to Secondary & Case AC3000V, 1 minute(leakage current less than5mA) for type test, (3
second for production).
9. INSULATION RESISTANCE
Input to output: no less than 50 MOHM(500VDC)
10. LEAKAGE CURRENT
The leakage current shall be less than 0.25 mA for Class ‖ when power supply is operated
maximum input voltage and maximum load.
11. MAJOR MEASURE EQUIPMENT
11.1 AC SOURCE: CHROMA 61602
11.2 POWER METER: PF9800
11.3 ELECTRONIC LOAD: CHROMA 6312
11.4 OSCILLOSCOPE: Tektronix TDS 1012
11.5 MULTIMETER: Fluke 45
11.6 DC POWER: TPR-3003-2D
11.7 HI-POT TESTER:GOODWILL GPT-605
11.8 DWC2515
11.9 TERCHY MHU-1000A
12. PRODUCT EXTERNAL VIEW
CV1203E
CV1203A
