R48-5800A

Anuncio
DC Power for
Business-Critical Continuity
R48-5800
Rectifier, 120A
-48VDC, 5800W
Features and Benefits
Industry leading power density,
3
800w/dm
Optimized size for best cabinet rack
spae utilization
DSP (Digital Signaling Processor)
means fewer components,
optimized operation and active load
sharing for increased reliability
Compliant with global standards
delivers quality, performance and
reliability no matter what the
application or location demands
High surge/transient immunity, 6kV
High efficiency, up to 93% reduces
power consumption for lower
operating costs
Hot pluggable facilitates future
extensions
Wide input voltage range operates
in the most demanding
environments where input voltage
changes
Wide temperature operating range
o
o
o
o
(-40 C / -40 F to +65 C / 149 F)meets the harshest climatic
environment requirements
Description
The R48-5800 rectifier converts 380~480 Vac 3-phase AC supply voltages into stable
nominal -48 VDC voltage adjustable to the needs of the application. The R48-5800 is a
constant power rectifier designed with the latest patented switch-mode technology
using DSP (Digital Signal Processor) functionality for efficient operation. For a higher
load capacity, rectifiers can be connected in parallel and intelligent control can be
added with the help of a separate controller.
DC Power for
Business-Critical Continuity
R48-5800
Technical Specifications,R48-5800
AC Input
Input voltage, nominal
380 to 480 V AC
Input voltage, permitted variation
Line frequency
Max input current
260 to 530 V AC
45 to 65 Hz
12 A
Power factor
THD, Total harmonic distortion
0.99
<5% from 50 to 100% of rated load
Temperature derating
Control and Monitoring
Rectifier alarm and signaling
Visual indications
Red LED
Blinking Red LED
Current Indicator
% of output power
120
-42 to 58 V DC
5800W@Vout >48 V DC
See diagram
120 A
0 to 120 A
93%
<1mV at 5 to 100% of rated load
<32 dBrnc at 0 to 100% of rated load
See diagram
-40 to +65 C, -40 to +149 F
o
o
-40 to +80 C, -40 to +176 F
0 to 95%
2000 m, 6560 ft at full power
EN 300 386:2001 class B
Safety
IEC 60950, EN 60950, UL 60950
Mechanics
Dimensions( Hx W xD)
85.5x 224.5x 357.5mm (Excluding panel)
Weight
87.5x243.5x 371.5mm (Including panel)
< 8kg
Other Parts
Controller units
See separate ACU and SCU datasheets
o
80
60
40
20
-30
-20
-10
0
10
20
30
40
50
60
70
80
475
500
525
550
Temperature (C)
Output Power vs. Input Voltage
120
Alarm and status reported via CAN bus to system Controller
Green LED = Normal operation; Yellow LED = Alarm;
HVSD indicting lamp.
Fan Fault.
A 10-segment green LED is located on the front panel to
represent output current, each segment represents 10A.
Environmental
Temperature range, operating
Temperature range, storage
Relative humidity
Altitude
EMC
100
0
-40
% of max. output power
DC Output
Output voltage, adjustment range
Output power
Output power, derated for input voltage
Output current
Output current limit set point
Efficiency
Psophometric noise (system)
Output Power vs. Temperature
100
80
60
40
20
0
250
275
300
325
350
375
400
425
450
Input voltage (VAC)
o
Ordering Information
Product name
Rectifier R48-5800
Emerson Network Power.
The global leader in enabling
business-critical continuity.
AC Power
Embedded Computing
Outside Plant
Racks and Integrated Cabinets
Connectivity
Embcddcd Power
Power Switching & Controls
Services
DC Power
Monitoring
Precision Cooling
Surge & Signal protection
Emerson Network Power
Energy Systems AB
SE-141 82 Stockholm, Sweden
Emerson Network Power
Energy Systems, North America
1122 F Street, Lorain, OH 44052
Phone: +46-8-721-6000
Fax:
+46-8-721-7177
www.emersonenergy.com
Phone: +440-246-6999
Fax:
+440-246-4876
www.emersonnetworkpower.com/energysystems/
Emerson Network Power
Co Ltd., China
No. 1 Kefa Rd., Science & Industry Park
Nanshan District 518057, Shenzhen, China
Phone: +86-755-8601-0808
Fax:
+86-755-8601-0909
www.emersonnetworkpower.com.cn
Emerson Network Power and the Emerson
Network Power logo are trademarks and
service marks of Emerson Electric Co.
2005 Emerson Electric Co.
2007.07
