Solar Power Transformer Station
Product Features
Highly integrated
■■ LV panel/transformer/MV switchgear have been
prefabricated and installed in a 20-feet container
■■ Compact container and highly integrated design for
efficient transportation and installation
Advanced intelligence
■■ Anti-PID function to ensure power generation
■■ Detects the operating status of the ring main unit,
transformer, and low-voltage cabinet in real time.
■■ Smart communication box which integrates Anti-PID,
PLC, data logger for fast networking of the PV plant.
Safe and reliable
■■ Solid structure design and safe electrical design
■■ High IP protection level for LV/MV rooms adapt to high
temperature, salt, and extremely cold etc. environment
Fast deployment and lower cost
■■ Standardized 20-feet container for fast deployment and
easy installation
■■ Cables between internal equipment have been
connected, only LV cables, MV cables and
communication cables to external equipment need to
routed out onsite
Function Diagram
PV+ESS for the Future
Technical Specification
Items
SPTS6580K
LV Panel
Rate voltage
800Vac
Number of branch inputs
MCCB (250A/800V/3P, 2*14 pcs)
Number of main outputs
ACB (3200A/800V/3P, 2*1 pcs)
Low voltage panel
2 pcs
Fuse
300A/800 Vac/1P, 84 pcs
Transformer
Rated power
[email protected]
Max. power
[email protected]
LV voltage
800Vac
Max. input current at nominal voltage
2526A*2
MV voltage
20kV/22kV/30kV/33kV
Efficiency
≥99%
Impedance
7%(0~+10%)@6580kVA
Transformer type
Oil-immersed
Oil type
Mineral oil (PCB free)
Winding material
Al / Al
Cooling method
ONAN
Vector group
Dy11y11
Insulation class
A
MV Switchgear
Scheme
CCV
Insulation
SF6
Rated voltage
24kV/36kV/40.5kV
Rated current
630A
Rated frequency
50/60Hz
Qty. of feeder
3
Protection
AC input protection
Yes
Transformer protection
Oil-temperature, oil-level, oil-pressure
Relay protection
50/51, 50N/51N
LV surge protection
AC Type II (optional: AC Type I + II)
General
Dimension (W×H×D)
6058×2896×2438 mm
Weight
<25T
IP grade
IP54
Auxiliary transformer
5kVA (Optional: max. 40kVA), Dyn11, 800V/400V
Operating temperature range
-25ºC~60ºC
Max. operating altitude
2000m
Allowable relative humidity range (noncondensing)
0-95%
Communication with inverter
RS485 / PLC (optional)
Communication with monitoring center
Compliance
RS485, Ethernet (optional: optical fiber)
IEC 60076, IEC 62271-200, IEC 62271-202, IEC 61439-1, EN50588-1
●● Specifications are subject to change without prior notice.
Kehua Tech
Add: No. 457, Malong Road, Torch High-Tech Industrial Zone, Xiamen Fujian China
Tel: +86-592-5160516
Fax: +86-592-5162166
www.kehua.com
