M-4 en - envases sanz belda, sl

M-4 T.E-4
Technical comercial data ref.
Serie MASTER
CAPO011602 15-07-15
TECHNICAL DATA:
Material:
Polypropylene copolymer of first quality, suitable for
contact with food according to current regulations.
Colours:
White standard. Consult for other colours.
Useful Volume:
Volume to the edge:
4.0 litres
4.6 litres
Weight of the bucket:
Weight of the lid:
Weight of the handle (plastic):
Total Weight:
182 g. approx.
53 g. approx.
7.5 g. approx.
242.5 g. approx.
Decorative surface flat inks:
120 x 555 mm (height x perimeter)
Design surface photographic finish 130 x 565 mm (height x perimeter)
MEASURAMENTS:
204
187
200
167
Measuraments in millimetres
GROUPING OF TRANSPORT:
Buckets:
Pallet dimensions:
1020 buckets per pallet
1250 x 1025 x 1170 (see drawing)
Lids:
204 lids per box, this serves as a
packaging of transportation
420 x 220 x 1000
Box dimension:
ENVASES SANZ BELDA ,S.L.Polígono San José, A, Parc. 7 CP: 46812 Aielo de Malferit, Valencia (España)
Tel.: 96 236 02 32 Fax: 96 290 43 65 E-mail: www.envasessanzbelda.es // [email protected]
