ATS Airspace: Fuerteventura CTR (class D) RWY 01 RWY 19

GND
121.700
(rodadura)
TWR
118.475
(1000ft AGL/GND)
GCCA_E_APP
129.300
(FL125/MSL)
GCCC_NE_CTR
129.100
(FL460/MSL)
GCFV
Fuerteventura
ATS Airspace: Fuerteventura CTR (class D)
RWY 01
SID: KORAL1Z, LARYS2Q, LORPO1Q, LUNOB1Q,
MAPED1Q.
RNAV: KORAL7Q, SAMAR7Q, VASTO7Q, SAMAR1Z,
VASTO1Z
STAR: GDV1S, KOPUD1S, RUSIK1B.
RNAV1: RUSIK3S, TERTO5S
ILS: IFV (Freq. 109.50/OBS: 006º)
Aproximaciones disponibles a la RWY 01R:
Aproximación
IAFs
Notas
(altura mínima)
ILS Z
SOTAD requiere
ILS Y
TENDA (5000ft)
BRNAV-1
VOR
SIRPU(5000ft)
FRUSTADA A TENDA 4000’
LOC Z
SOTAD (5000ft)
LOC Y
ILS X
FV (4000ft)
FRUST. A FV 4000’
RWY 19
SID: KORAL1Y, LARYS1R, LORPO1R, LUNOB1R,
MAPED1R.
RNAV1: KORAL7R, SAMAR7R, VASTO7R
STAR: GDV1W, KOPUD1W, RUSIK1B.
RNAV1: RUSIK3W, TERTO5W.
ILS: IFA (Freq. 111.30/OBS: 186º)
Aproximaciones disponibles a la RWY 19L
Aproximación
IAFs
Notas
(altura mínima)
BAMKU RNAV-1
ILS Z
BAMKU(6000’)
ILS Y
TENDA (5000ft)
LOC Z
KEMEV (4000’)
LOC Y
VOR
TA: 6000 ft
NAVAIDS:
•
•
•
FTV (DVOR/DME) 114.100
FV (L)
397.000
01R (GP)
332.600
RMK:
•
•
UTILIZATION OF RUNWAY 01L/19R: Due to short distance between runways 01L/19R and 01R/19L it is not allowed
to use them simultaneously. Runway 01L/19R will start on service exclusively when runway 01R/19L is out of
service. The putting into service of runway 01L/19R will be announced by NOTAM.
AD traffic circuit: Only to the East of the airport.
-- THIS DOCUMENT IS NOT VALID FOR REAL OPERATIONS --
UPDATE:VERSION 4, 08/10/16
