Heavy Duty Pentium/Celeron CPU Cooler Fan

Heavy Duty Pentium/Celeron CPU Cooler Fan
(Socket 7/370)
Product ID: FANP100
The StarTech Socket7/370 CPU cooling fan is a combination heatsink and fan
designed for cooling Socket 370 (PPGA) Celerons, FC-PGA (Flip-chip) Pentium III,
Socket 7 Pentiums, AMD K6, K6-2, K6-3, and Cyrix chips. It sports an extra-large
heatsink with enough cooling capacity for even the newest and fastest processors. A
quiet running 5 cm brushless ball bearing DC motor coupled with a high-efficiency
blade design is capable of moving 9 CFM (cubic feet per minute) of air. Power is
supplied to the fan using a standard LP4 (hard drive power connector) pass through
plug.
www.startech.com
1 800 265 1844
Applications
•
•
•
•
For Socket 370 (PPGA) Celerons, Socket 7 Pentiums, AMD K6, K6-2,
K6-3, and Cyrix chips.
Can be used as a replacement CPU fan for Pentium 100 or faster
Socket 7 based computers.
This fan is connected to the power supply. Refer to FANP1003LEAD
for a fan that is connected to an ATX motherboard.
Use thermal heatsink compound (HEATGREASE or HEATGREASE10)
for optimal performance
Features
•
Steel clip provides a secure fit
www.startech.com
1 800 265 1844
Warranty
2 Years
Hardware
Tipo de Rodamiento del Ventilador
Ball Bearing
Rendimiento
Especificaciones Generales
1.95 x 1.95 x 0.4
113 grams
12V
2.1 x 1.9 x 0.8
28
4500
50 x 50 x 10
53 x 48 x 20
9.3
Aluminum
Ball Bearing
C3, Cyrix III & Cyrix MII up to 500 MHz
K-6 series up to 500 MHz
LP4 connector
Pentium II & III up to 500 MHz
Plastic
Socket 7 & Socket 370
RPM
4500
Velocidad de Flujo de Aire
9.3 CFM
Conector(es)
Tipo(s) de Conector(es)
1 - Molex Fan (3 pin, TX3) Hembra
Características
Físicas
Color
Black
Peso del Producto
4 oz [113 g]
Información de la
Caja
Peso (de la Caja) del Envío
0.2 lb [0.1 kg]
Contenido de la Caja
Incluido en la Caja
1 - Socket 7/370 Pentium/Celeron CPU Fan
Product appearance and specifications are subject to change without notice.
www.startech.com
1 800 265 1844
