Experimental and Theoretical Study of the Synthesis of a Deep
Eutectic Solvent Based on Protonated Caffeine, Ethylene Glycol,
and ZnCl2
Laura Sofía Benavides-Maya 1 , Manuel Felipe Torres-Perdomo 1 , Luz M. Ocampo-Carmona 1
and Luver Echeverry-Vargas 2, *
1
2
*
Academic Editor: Vito Capriati
Received: 1 February 2025
Revised: 1 March 2025
Departamento de Materiales y Minerales, Universidad Nacional de Colombia, Medellin 050034, Colombia;
[email protected] (L.S.B.-M.); [email protected] (M.F.T.-P.)
Department of Metallurgical Engineering, University of Concepcion, Concepción 4070371, Chile
Correspondence: [email protected]
Abstract: In this study, a deep eutectic solvent (DES) incorporating protonated caffeine
(CafCl), ethylene glycol (EG), and zinc chloride (ZnCl2 ) was synthesized and characterized
for the first time. Caffeine was protonated using an optimized procedure in an anhydrous medium to enhance its interaction with the system, and its structure was confirmed
by FTIR spectroscopy, NMR, and thermogravimetric analysis (TGA), evidencing the formation of the N-H bond in the imidazole ring. A eutectic mixture with a molar ratio
of ETG:ZnCl2 :CafCl of 1:2:0.1 was synthesized, and its characterization confirmed the
formation of hydrogen bonds and the coordinative interaction between the components.
Additionally, computational simulations based on COSMO-RS and ab initio molecular
dynamics (AIMD) were conducted to analyze the charge distribution and the stability of the
hydrogen bond network in the eutectic mixture. Sigma profiles revealed that protonated
caffeine possesses highly polar regions capable of establishing strong interactions with EG
and ZnCl2 , enhancing the system’s stability. Furthermore, radial distribution functions
(RDFs) showed a decrease in the interaction distance between key atoms after incorporating
protonated caffeine. The results suggest that this novel DES has promising potential for
industrial applications, especially in the extraction of sulfur compounds from fossil fuels
due to the activation of the imidazole ring of caffeine. However, further studies are needed
to optimize its operating conditions and evaluate its performance on an industrial scale.
Accepted: 6 March 2025
Published: 14 March 2025
Citation: Benavides-Maya, L.S.;
Keywords: deep eutectic solvents (DESs); protonated caffeine (CafCl); ab initio molecular
dynamics (AIMD)
Torres-Perdomo, M.F.;
Ocampo-Carmona, L.M.;
Echeverry-Vargas, L. Experimental
and Theoretical Study of the Synthesis
of a Deep Eutectic Solvent Based on
Protonated Caffeine, Ethylene Glycol,
and ZnCl2 . Molecules 2025, 1, 0.
https://doi.org/
Copyright: © 2025 by the authors.
Licensee MDPI, Basel, Switzerland.
This article is an open access article
distributed under the terms and
conditions of the Creative Commons
Attribution (CC BY) license
(https://creativecommons.org/
licenses/by/4.0/).
Molecules 2025, 1, 0
1. Introduction
The synthesis of alternative solvents has emerged as a necessary response to the
growing environmental challenges posed by the extensive use of conventional solvents
in various industrial processes. These processes involve the use of large amounts of
organic solvents for chemical reactions, extraction, separation, and purification, among
other applications [1]. Although these solvents play a crucial role in chemical processes
by improving solubility, dissolution capacity, and chemical stability, many are highly toxic
and have adverse effects on both the environment and human health [2].
One promising alternative to conventional solvents is ionic liquids (ILs), which are
defined as salts that remain in a liquid state at temperatures below 100 ◦ C, with many
remaining liquids at room temperature. ILs consist of an organic cation and an organic or
https://doi.org/10.3390/molecules1010000
Molecules 2025, 1, 0
2 of 17
inorganic anion, forming chemically stable species due to strong electrostatic interactions
between ions [3]. This unique structure imparts ILs with distinctive properties, such as low
vapor pressure, chemical and thermal stability, and the ability to dissolve both organic and
inorganic compounds [4].
Despite the advantages of ILs, their synthesis can be complex and often involves
costly components, prompting interest in deep eutectic solvents (DESs) as a more accessible
alternative. DESs are mixtures of two or more chemical species, typically referred to as
hydrogen bond acceptors (HBAs) and hydrogen bond donors (HBDs). When combined
in specific molar ratios, these mixtures undergo a significant reduction in their melting
points, becoming liquid at temperatures below 100 ◦ C [5]. The components commonly
used for DES synthesis are generally safe, inexpensive, and readily available, making them
attractive for various industrial applications [6]. A common example involves quaternary
ammonium salts, such as choline chloride, as HBAs, while urea, alcohols, amides, amines,
or carboxylic acids serve as HBDs [7,8]. The precise combination of HBAs and HBDs
directly influences the physicochemical properties of DESs, enabling the tailoring of their
applications. In particular, the use of metal salts as HBAs and alcohols as HBDs has
been proven advantageous due to their ability to form stable structures through hydrogen
bonding and metal coordination [9].
Since 2001 [10], efforts have been made to develop deep eutectic solvents (DESs) as
alternative sustainable solvents, particularly in extraction and separation processes. The
versatility of DESs has allowed their application in various fields, including catalysis,
electrochemistry, and biomass processing. One of their most studied applications is in
extractive and oxidative desulfurization processes, which aim to overcome the limitations of
conventional hydrodesulfurization (HDS). These limitations include extreme temperature
and pressure conditions, high energy and hydrogen consumption, high catalyst costs,
and low efficiency in removing aromatic sulfur compounds such as benzothiophene (BT),
dibenzothiophene (DBT), and their alkyl derivatives [11–13].
DESs offer a promising approach to fuel desulfurization, supporting stricter environmental regulations that limit sulfur content in fuels to 10 ppm in Europe, China, and
the United States [14,15]. Various DESs have been synthesized and evaluated for their
sulfur extraction efficiency. For example, Gano et al. [16] demonstrated that FeCl3 -based
DESs exhibit over 90% DBT solubility, outperforming ZnCl2 -based DESs. Further studies
optimized DES compositions, achieving sulfur removal efficiencies of up to 99.5% in some
cases [17–19].
Given these advancements, this study proposes the incorporation of caffeine into DES
synthesis due to its unique chemical structure. Caffeine contains a pyrimidinedione and an
imidazole ring, making it a versatile hydrogen bond donor and acceptor. Its widespread use
in organic synthesis stems from its low toxicity, ease of handling, and lower cost compared
to imidazole, which was priced at 130 USD/kg in January 2025 [20].
Although IL-based extractions have shown promising results, DESs have gained
attention for their potential in sulfur removal from fossil fuels. In 2013, Li et al. [21]
synthesized DESs using choline chloride, tetramethylammonium chloride, and tetrabutylammonium chloride as HBAs, combined with various alcohols and acids as HBDs. A
TBAC/polyethylene glycol DES achieved 82.83% BT removal in a single cycle and up to
99.48% after five cycles.
This study explores, for the first time, the incorporation of protonated caffeine into
DES synthesis. Its heterocyclic structure enables strong hydrogen bonding interactions, stabilizing both polar and nonpolar compounds [22]. In its protonated form, caffeine enhances
electrostatic interactions within the DES, improving molecular stability. Additionally, its
dual role as a hydrogen bond donor and acceptor expands the potential applications of
Molecules 2025, 1, 0
3 of 17
DESs. While DESs have proven effective in extractive desulfurization, integrating caffeine
opens new possibilities in separation and catalytic processes, with potential applications in
fuel desulfurization pending further optimization and evaluation.
2. Results and Discussion
2.1. Activation of Caffeine’s Imidazole Ring
Figure 1 presents the thermogravimetric analysis results for pure caffeine and protonated caffeine. In the case of protonated caffeine, a thermal degradation event is observed
between 70 and 75 ◦ C, corresponding to the release of hydrogen chloride from the caffeine
molecule. This process accounts for a weight loss of 15.1%. Comparing this value with
the theoretical weight percentage of HCl in the CafCl molecule (15.8%), a relative error of
4.43% is calculated, indicating a purity of 95.57% for the protonated CafCl.
In contrast, the thermogravimetric analysis of pure caffeine reveals a single thermal
event occurring at approximately 170 ◦ C, which is attributed to sublimation. Under these
conditions, solid caffeine transitions directly into vapor without passing through a liquid
phase, as reported in previous studies [23,24]. Once the absence of solvent in the protonated
caffeine was confirmed (TGA analysis), the FTIR spectrum was taken as observed in
Figure 2.
Figure 1. Thermogravimetric analysis of pure and protonated caffeine.
The presence of the vibrational mode of the N-H bond was identified, which, according
to Salami and Ezabadi, occurs at 3306 cm−1 [25]. This vibrational mode corresponds to
the symmetric stretching of the N-H bond, consistent with the experimental spectrum
presented in Figure 2. Furthermore, this observation aligns with Wade’s description [26],
which indicates that the N-H stretching frequency should appear as a broad and moderately
intense band, near 3300 cm−1 .
In contrast, the spectrum of pure caffeine revealed the absence of bands corresponding
to amino groups (N-H). Instead, molecular vibrations characteristic of other functional
groups were observed, including the following: C=O at 1700 cm−1 , C=C at 1640 cm−1 ,
asymmetric bending of CH3 at 1462 cm−1 , symmetric bending of CH3 at 1380 cm−1 , C-H
at 3050 cm−1 , and C-N at 1200 cm−1 [27]. These bands are commonly found in both pure
caffeine and caffeine hydrochloride (CafCl).
Molecules 2025, 1, 0
4 of 17
Figure 2. Comparative FTIR spectra of pure caffeine and protonated caffeine (CafCl).
Additionally, the presence of protonated caffeine was confirmed through Proton
Nuclear Magnetic Resonance (1 H NMR) analysis. The 1 H NMR spectrum provided insights
into the interactions between hydrogen atoms and their neighboring atoms within the
molecule. These interactions were expressed as distinct chemical shifts, allowing the
identification of different chemical environments of hydrogen atoms in the sample [28].
The 1 H NMR spectrum of CafCl is shown in Figure 3.
Figure 3. NMR spectrum of protonated caffeine (CafCl).
From the spectrum, five significant peaks corresponding to the five protons present in
the CafCl molecule can be observed. These peaks were compared with values reported in
the literature to determine the chemical shift (δ) and resonance frequencies for each proton
group in the molecule, as summarized in Table 1.
Molecules 2025, 1, 0
5 of 17
Table 1. Proton chemical shift comparison of caffeine and CafCl.
Proton
8
11
13
14
15
Theoretical δ
Caffeine
Literature δ
Caffeine
Experimental δ
CafCl
Literature δ
CafCl
Experimental
Peak Integration
7.5
3.48
3.51
4.0
7.58
3.37
3.55
4.01
7.27
3.27
3.71
4.13
8.5
7.99
3.13
3.33
3.82
11.27
1.0
3.10
3.10
3.04
0.99
The δ values are influenced by the electronic environment surrounding the nucleus,
which can be affected by factors such as the presence of functional groups, multiple bonds,
and electronegative atoms. In pure caffeine, the methyl groups (CH3 ) typically appear as
singlet peaks in the NMR spectrum, with chemical shifts ranging from 2.8 to 4 ppm. This is
consistent with the observations in Figure 3 for protons 11, 13, and 14 [29]. Proton 8, located
in the imidazole ring, typically resonates in the lower chemical shift region (approximately
7–8 ppm). This shift is attributed to electronic shielding caused by electronegative atoms
and π-electron delocalization in the aromatic system. In Figure 3, proton 8 is observed at
7.25 ppm, in agreement with literature values [29].
An additional peak, corresponding to proton 15, is present in the CafCl spectrum
and represents the proton attached to the nitrogen atom of the imidazole ring, introduced
through caffeine protonation. This proton is absent in the spectrum of pure caffeine.
According to Salami and Ezabadi [25], this proton resonates at 11.27 ppm; however, their
analysis was conducted in dimethyl sulfoxide (DMSO) as the solvent. The solvent’s
properties significantly influence the chemical shift, as interactions between the sample and
the solvent can alter the electronic distribution. In the case of CafCl, this proton is expected
to experience a slight shift towards lower values (higher ppm) compared to free amino
groups. This is attributed to additional delocalization of electron density, likely caused by
hydrogen bond formation [30].
2.2. Synthesis of Protonated Caffeine-Based DES
The formation of the binary DES (ETG:ZnCl2 ) is primarily attributed to the ability of
ETG to donate hydrogen bonds via its two hydroxyl groups, enabling the formation of
hydrogen bonds with the chloride anions (Cl− ) of ZnCl2 [31]. Additionally, the possibility
of coordination complexes forming between Zn2+ ions and the hydroxyl groups of ETG is
significant, as Zn2+ , acting as a Lewis acid, exhibits a strong affinity for the oxygen atoms
in the hydroxyl groups [32].
The system’s capacity to incorporate CafCl can be explained by the formation of
hydrogen bonds between the carbonyl groups and nitrogen atoms of CafCl with the
hydroxyl groups of ETG. Furthermore, it is plausible that stable coordination complexes
are formed between Zn2+ ions and the nitrogen atoms of CafCl, further enhancing the
solubility of CafCl in the DES [33,34]. To better understand these interactions, Raman
spectroscopy was used to characterize the pure components (CafCl, ZnCl2 , ETG), the
binary DES (ETG:ZnCl2 ), and the ternary DES (ETG:ZnCl2 :CafCl). The corresponding
spectra are presented in Figure 4.
For pure CafCl, several significant bands are observed in the Raman spectrum: a
vibration at 551 cm−1 attributed to the O=C-N deformation of the pyrimidinedione ring [35];
bands at 1659 and 1700 cm−1 corresponding to C=O stretching vibrations [36]; a band at
2952 cm−1 characteristic of CH3 stretching [37]; and a band at 3447 cm−1 , indicative of N-H
vibration, which confirms caffeine protonation [38].
Molecules 2025, 1, 0
6 of 17
Figure 4. Raman spectra of pure compounds and synthesized DES.
For ZnCl2 , two prominent bands are observed at 81 cm−1 and 281 cm−1 , the latter
being associated with the stretching vibration of the Zn-Cl bond [39]. In the case of EG,
the most intense Raman bands appear between 2800 and 3000 cm−1 , corresponding to
CH2 stretching, and a broad band between 3300 and 3600 cm−1 , indicative of OH group
vibrations, as reported in the literature [40].
In the binary DES (ETG:ZnCl2 ) spectrum, notable similarities with the pure ETG
spectrum are observed. Additionally, a band at 282 cm−1 , which is present in the pure
ZnCl2 spectrum, is also observed in the DES spectrum. However, this band appears with
reduced intensity in the DES, suggesting its involvement in hydrogen bond formation with
the OH groups of ETG.
In the ternary DES (ETG:ZnCl2 :CafCl) spectrum, the OH group band shifts to a lower
wavenumber (3230 cm−1 ) compared to the binary DES (EG:ZnCl2 ) spectrum, where it
appears at 3310 cm−1 . Additionally, an increase in band width is observed, which is a
well-documented indicator of hydrogen bond formation, as reported in the literature [41].
Furthermore, the characteristic ZnCl2 band at 281 cm−1 exhibits a significant decrease
in intensity, supporting the hypothesis that ZnCl2 participates in hydrogen bond formation
with the OH groups of EG. Similarly, the characteristic CafCl band at 551 cm−1 , attributed
to O=C-N deformation, also shows a reduction in intensity, suggesting its involvement in
hydrogen bond formation with the OH groups of ETG.
2.3. Sigma Profile
The surface polarization charge density and sigma profile (σ) ETG, ZnCl2 , and CafCl
molecules are depicted in Figure 5 to identify regions prone to hydrogen bond formation
Molecules 2025, 1, 0
7 of 17
and to characterize the distribution of charges on their molecular surfaces. For ETG, its
2
sigma profile spans the range of ±0.016 e/Å , displaying two prominent peaks. These
peaks reveal negative regions localized on the oxygen atoms associated with hydroxyl
groups and positive regions on the hydrogen atoms.
Notably, due to the inversion of the polarization charge density sign (σ) relative to the
actual polarity of the molecule, the primary peak for oxygen atoms appears on the right
2
side of the profile (approximately +0.0133 e/Å ), while the peak corresponding to hydrogen
2
atoms is located on the left side (around −0.0136 e/Å ). Both peaks surpass the hydrogen
2
2
bond threshold (±σhb = ±0.0084 e/Å ), and since their magnitudes exceed ±0.01 e/Å ,
these regions are classified as strongly polar. Consequently, these areas on ETG’s molecular
surface are well suited for forming hydrogen bonds, which aligns with the compound’s
high solvation capacity and strong intermolecular interactions. For ZnCl2 , the sigma profile
is predominantly located between −0.01 e/Å2 and +0.006 e/Å2 , with prominent peaks
reflecting the contributions of the negative charges from the chlorine atoms and the positive
charge from the zinc atom. In the σ representation, the peak corresponding to chlorine
is found around +0.0045 e/Å2 (right side), while the peak associated with zinc appears
near −0.008 e/Å2 (left side). These σ values lie within the range considered nonpolar
(±0.0084 e/Å2 ), indicating a very limited or nearly nonexistent capacity to form strong
hydrogen bonds. Consequently, ZnCl2 is distinctly different from the ETG molecule in
terms of its potential for molecular interactions through hydrogen bonding.
Figure 5. σ-profiles y polarización superficial determinados mediante COSMO-RS para: (a) ETG,
(b) ZnCl2 y (c) Cl-Caff.
In contrast, the CafCl molecule exhibits a broader sigma profile, spanning approximately ±0.02 e/Å2 , with dominant peaks arising from the highly negative regions of the
oxygen and chlorine atoms and the highly positive regions of the hydrogen atoms. Due to
the inversion of the polarization charge density (σ) sign relative to the actual polarity, the
peaks for oxygen and chlorine are located on the right side of the profile (approximately
+0.0104 e/Å2 for oxygen and +0.018 e/Å2 for chlorine), while the peaks for hydrogen
appear on the left side (near −0.019 e/Å2 , −0.0139 e/Å2 , and −0.0107 e/Å2 ). These values
significantly exceed the hydrogen bond threshold of ±0.0084 e/Å2 , indicating that the
CafCl molecule has several highly polar regions (beyond ±0.01 e/Å2 ) with strong potential
Molecules 2025, 1, 0
8 of 17
to form hydrogen bonds. Thus, CafCl exhibits behavior similar to ETG in its capacity to
establish intermolecular interactions through hydrogen bonding.
2.4. Radial Distribution Functions
To further investigate the interactions and structure of the DES under study, an analysis
of the radial distribution function (RDF) for atom–atom interactions was performed for both
the eutectic mixture ETG:ZnCl2 and the eutectic mixture ETG:ZnCl2 :CafCl. Understanding
the predominant interactions is essential to elucidate the behavior of this system. The RDF
describes the probability of finding a particle at a certain distance from another and can be
determined using the following Equation (1) [42]:
g (r ) =
∆Ni,j (r, r + ∆r ) · V
4πr2 ∆rNi Nj
(1)
where Ni and Nj represent the number of particles i and j, and V is the particle volume.
Furthermore, r is the distance between particles i and j, and ∆Ni,j indicates the average
number of particles j at a distance r to r + ∆r from particle i.
The analysis of the sigma profile between ETG molecules shows that oxygen atoms act
as hydrogen bond acceptors, while hydrogen atoms can serve as donors. Consequently, the
radial distribution function between ETG molecules exhibits a prominent peak at 1.93 Å,
indicating a high probability of interaction between the hydrogen and oxygen atoms of
different ETG molecules, as shown in Figure 6.
Regarding the interactions between ETG and ZnCl2 , the results show that Zn atoms
have a higher probability of interacting with the oxygen atoms of ETG at 2.17 Å, while
chlorine atoms associate with the hydrogen atoms of ETG at 2.61 Å. Based on the sigma
profile of ZnCl2 , it is reasonable to infer the existence of strong O–Zn interactions between
ETG and ZnCl2 , while the interactions between chlorine and hydrogen atoms would be
considerably weaker.
Figure 6. Radial distribution functions calculated at 50 ◦ C for the binary DES composed of ETG and
ZnCl2 .
Upon incorporating the CafCl molecule into the binary DES system, a reduction in
the interaction distance of the RDF) between ETG molecules is observed, reaching 1.77 for
O-H pairs. Similarly, the RDF between ETG and ZnCl2 decreases to 2.11 Å, for interactions
between the O-Zn atoms of both molecules. Likewise, the interaction distance between
H-Cl atoms is reduced to 2.17.
Molecules 2025, 1, 0
9 of 17
A noteworthy aspect is the predominant interaction between the CafCl molecule and
the binary DES. The RDF reveals that the hydrogen atom attached to the nitrogen of the
imidazole ring exhibits a strong interaction with the oxygen of ETG, at a distance of 1.69 Å,
making it the most significant interaction within the ternary DES. Additionally, a notable
interaction is identified between the chloride ion of CafCl and the Zn of ZnCl2 , with a
distance of 2.29. These interactions are illustrated in Figure 7.
Figure 7. Radial distribution functions calculated at 50 ◦ C for the tertiary DES composed of ETG,
ZnCl2 and CafCl.
The expected behavior of the ternary DES can be approximated based on binary systems composed of ethylene glycol and zinc chloride, for which viscosity, density, melting
point, and ionic conductivity values are well documented [43,44]. The incorporation of
caffeine into these binary systems may modify these properties by influencing the hydrogen
bonding network and ionic mobility. The system’s density could slightly decrease, as caffeine is an organic compound with a lower density than metal halides. Regarding viscosity,
an increase is likely due to the formation of additional interactions between protonated
caffeine and other components, which restrict molecular motion. The melting point may
rise since the presence of organic salts in DESs generally enhances thermal stability. Finally,
ionic conductivity may vary depending on caffeine’s effect on the dissociation of charged
species and the mobility of ions in the mixture.
3. Materials and Methods
3.1. Activation of Caffeine’s Imidazole Ring
3.1.1. Chemical Reagents
Commercial caffeine (Sigma-Aldrich, St. Louis, MO, USA 99%) was dried in an oven
at 80 ◦ C for 24 h to remove any residual moisture prior to use. Ethanol for synthesis (SigmaAldrich, 99%) was treated with zeolites to minimize water content and ensure the solvent
was as dry as possible. Sodium chloride (Merk, Darmstadt, Germany 99.5%) was similarly
dried at 80 ◦ C for 24 h before use. Sulfuric acid (Aldrich, St. Louis, MO, USA, 95–97%)
was used without further purification. It is important to emphasize that all reagents were
of analytical grade, and stringent precautions were taken to avoid contamination with
moisture.
3.1.2. Reaction Setup and Procedure
The protonation of caffeine at one of the nitrogen atoms in the imidazole ring was
performed following the methodology described by Salami and Ezabadi [25], in which
Molecules 2025, 1, 0
10 of 17
caffeine reacts with 37% hydrochloric acid in an aqueous medium at 70 ◦ C for 48 h. To
optimize the reaction conditions and ensure the desired product, several modifications
were introduced. One of the key improvements was the removal of water from the system,
which reduced the reaction time to just 3 h. This was achieved by leveraging the high
solubility of gaseous hydrogen chloride in anhydrous ethanol, significantly enhancing the
efficiency of the process.
Furthermore, the presence of water can affect protonation, as it acts as a weak base and
competes with caffeine for protons. An excess of water may capture the available protons,
thereby reducing the effectiveness of the process. To mitigate this effect, the reaction was
conducted in two distinct stages, as illustrated in Figure 8.
Figure 8. Setup for caffeine protonation.
•
First stage, production of anhydrous hydrogen chloride: Anhydrous hydrogen chloride was generated by the reaction between sodium chloride and sulfuric acid, as
shown in Figure 9. The system consisted of a round-bottomed flask containing sodium
chloride, with sulfuric acid added dropwise, while the mixture was maintained at a
constant temperature of 150 ◦ C using a heating mantle, as reported by Groover [45].
An excess of hydrogen chloride (5 molar equivalents) was bubbled into the ethanol solution containing caffeine to drive the equilibrium of the protonation reaction toward
product formation, ensuring complete protonation of the caffeine.
Figure 9. Reaction for production of gaseous hydrogen chloride.
•
Second stage, protonation reaction: The protonation reaction was carried out at 60 ◦ C
(Figure 10) with caffeine dissolved in anhydrous ethanol. A total of 110 mL of anhydrous ethanol was used to fully dissolve the caffeine at this temperature. The gaseous
hydrogen chloride produced in the first stage was continuously bubbled into the
ethanol solution, leading to the protonation of caffeine, which was indicated by the
precipitation of a white solid after 1 h of reaction.
Molecules 2025, 1, 0
11 of 17
Figure 10. Caffeine protonation reaction.
•
Purification of caffeine hydrochloride: The solid product, caffeine hydrochloride
(CafCl), was purified through rotary evaporation at 55 ◦ C and 200 mbar to eliminate
excess ethanol. The resulting solid was subsequently dried in a vacuum oven at 55 ◦ C
for 24 h to ensure complete removal of residual solvents. The final product yield
was 88.4%.
3.1.3. Characterization of Protonated Caffeine (CafCl)
The synthesized product, identified as caffeine hydrochloride (CafCl), was characterized using nuclear magnetic resonance spectroscopy (¹H NMR), Fourier-transform infrared
spectroscopy (FTIR), and thermogravimetric analysis (TGA). The ¹H NMR spectrum was
acquired using a Bruker Ascend III HD 600 MHz high-performance spectrometer equipped
with a Prodigy TCI 5 mm cold probe, with deuterated chloroform as the solvent (Bruker, Ettlingen, Germany ). The spectral data were processed with M-Nova 14.2 software, including
baseline correction applied to the raw signals.
For FTIR analysis, the sample was prepared using standard KBr pellet techniques and
analyzed over the spectral range of 4000–800 cm−1 using a Thermo Fisher Scientific Nicolet
6700 spectrometer equipped with an MCT detector (Thermo Fisher Scientific, Waltham, MA,
USA). The spectra were baseline-corrected to zero absorbance, smoothed, and normalized
to the maximum intensity signal to facilitate comparisons with reference databases and the
existing literature.
Thermogravimetric analysis (TGA) was performed on a TA Instruments Q500 instrument (TA Instruments, New Castle, DE, USA). The analysis focused on determining weight
loss and maximum decomposition temperature, with the raw data processed accordingly
to provide detailed thermal stability profiles.
3.2. Synthesis of Protonated Caffeine-Based DES
3.2.1. Chemical Reagents
The previously synthesized caffeine chloride (CafCl) was used along with the following chemical reagents: choline chloride (99%), zinc chloride (99%), urea (99%), and citric
acid (99.5%) from Sigma-Aldrich; tetraethylammonium bromide (98%), ethylene glycol
(99%), glycerol (98%), thiourea (99%), and malonic acid (99%) from Merck; tetraethylammonium chloride (99%), succinic acid (99%), acetamide (99%), N-methylurea (97%), adipic
acid (99%), benzoic acid (99%), and benzamide (99%) from Fisher Scientific (Waltham,
MA, USA).
Since the synthesis of deep eutectic solvents (DESs) using protonated caffeine has not
been reported in the literature, different combinations of HBAs and HBDs were tested until
the incorporation of protonated caffeine into the system was achieved, resulting in a liquid
with manageable viscosity at temperatures below 100 ◦ C. The HBAs and HBDs used in the
synthesis are detailed in Table 2.
DES synthesis was performed in a 50 mL beaker, maintaining the mixture at 50 ◦ C
with constant stirring at 200 rpm to ensure the incorporation of CafCl and prevent its
Molecules 2025, 1, 0
12 of 17
degradation. Initially, the HBAs and HBDs were mixed to form the eutectic mixture.
Once a decrease in the melting point of the mixture was observed, increments of 0.05 g of
protonated caffeine were added to determine the maximum amount that the system could
incorporate. The synthesized DESs are presented in Table 2.
Table 2. Observations of HBA and HBD combinations for protonated CafCl incorporation.
HBD
HBA
Molar Ratio
Observations About CafCl
Incorporation
Ethylene glycol (ETG)
Choline chloride (ChCl)
2:1
Partial incorporation with
high viscosity
Benzoic acid
Choline chloride
1:1
Crystal formation, partial
incorporation with high
viscosity
Benzamide
Choline chloride
2:1
Partial incorporation with
high viscosity
Ethylene glicol
Tetraethylammonium
bromide
2:1
Complete incorporation
with medium viscosity
Ethylene glicol
Hydrated iron chloride
3:1
Partial incorporation with
high viscosity
Ethylene glicol
Zinc chloride
2:1
Complete incorporation
with manageable viscosity
As shown in Table 2, the DES that demonstrated successful incorporation of CafCl was
composed of ETG and ZnCl2 in a molar ratio of 2:1. Up to 0.5 g of CafCl was incorporated
into the system, resulting in a ternary DES with a molar ratio of ETG:ZnCl2 :CafCl of 2:1:0.1.
3.2.2. Characterization of the Synthetized DES
To verify the structure of the binary DES (ETG:ZnCl2 ) and the ternary DES
(ETG:ZnCl2 :CafCl), characterizations were performed using Raman spectroscopy with
a Labram HR model instrument. This technique enabled the confirmation of hydrogen
bond formation between hydrogen bond acceptors and hydrogen bond donors. Additionally, the pure compounds used (ETG and ZnCl2 ) were also characterized. The obtained
spectra were analyzed using SpectraGryph 1.2 software, with baseline corrections applied
to ensure the accuracy of the results.
3.3. Computational Detail
3.3.1. COSMO-RS Calculation
The conductor-like screening model for realistic solvents (COSMO-RS) was used
to calculate the thermodynamic properties of the components of the ternary DES
(ETG:ZnCl2 :CafCl). Quantum-based equilibrium thermodynamic methods provide a robust framework to describe the molecular behavior of DES components, demonstrating
good qualitative and quantitative predictive capabilities [46]. The central principle of
COSMO-RS involves the creation of a virtual conductor, which simulates the introduction
of molecules into an aqueous medium through continuous solvation models to determine
their charge distribution [47].
Using charge distribution in the form of sigma profiles, which describe the polarity of
molecules, COSMO-RS qualitatively identified regions where hydrogen bonding occurs.
In sigma profile graphs, each peak represents the charge density of an atom within the
molecule. Atoms with a positive partial charge appear as negative charge densities, and
vice versa [47]. Sigma profiles represent surface charge densities rather than direct partial
Molecules 2025, 1, 0
13 of 17
charges. This results in an inversion of sign because the molecular cavity is embedded
in a virtual conductor, where the screening charge on the cavity surface compensates for
the molecular charge distribution. Consequently, a positively charged region within the
molecule induces a negative screening charge on the surface, and a negatively charged
region induces a positive screening charge, leading to the observed sign inversion in sigma
profiles [48].
To obtain sigma profiles, the geometry of each DES component was created and optimized using the density functional theory (DFT) electronic structure program DMol3 [49,50].
Graphical visualizations were generated with Materials Studio 2017 (Accelrys Software
Inc., San Diego, CA, USA). Once the structure of each component was optimized, the Becke–
Perdew [51] version of the Vosko–Wilk–Nusair functional [52] was applied to achieve a
more accurate characterization of the charge distribution [53]. Following the calculations,
the sigma profiles of each DES component were generated.
3.3.2. Ab Initio Molecular Dynamics (AIMD)
In this study, ab initio molecular dynamics (AIMD) was employed to investigate the
structure of the DES composed of ETG:ZnCl2 :CafCl. Figure 11 illustrates the molecular
structure of the components of the DES.
Figure 11. Schematic representation of ethylene glycol (ETG), zinc chloride (ZnCl2 ), and protonated
caffeine (CafCl).
The system under study incorporates a mixture with a molar ratio of ETG:ZnCl2 :CafCl
of 2:1:0,1. This ratio was selected based on experimental findings. A cubic simulation box
containing the binary DES composed of 4 ETG molecules and 2 ZnCl2 molecules was first
generated. Subsequently, one CafCl molecule was added to the previous system to obtain a
3
cubic simulation box (13 × 13 × 13 Å ) composed of 4 ETG molecules, 2 ZnCl2 molecules,
and 1 CafCl molecule.
The AIMD simulations were conducted using density functional theory (DFT) within
the DMol3 module of the Materials Studio software [54]. The structures of the compounds
were fully optimized using DFT with the generalized gradient approximation (GGA)
functional and the Becke–Lee–Yang–Parr (BLYP) basis set [55].
To observe and analyze the temporal evolution of the systems over time, AIMD
simulations were performed under periodic boundary conditions to avoid boundary effects.
The simulation boxes for both systems were equilibrated for 5.0 ps using a canonical
ensemble (NVT) with Nosé–Hoover chain thermostats applied to individual atoms, with
a time constant of 100 fs and a timestep of 1.0 fs [56]. The equilibrium temperature was
set at 300 K. For the subsequent production stage, a microcanonical ensemble (NVE) was
employed, with the temperature set at 323.15 K. The production time was set to 20 ps, while
the time constant and timestep remained the same as during the equilibration stage.
Molecules 2025, 1, 0
14 of 17
4. Conclusions
The growing need for more sustainable solvents has led to the development of deep
eutectic solvents (DESs) as a viable alternative to conventional solvents, due to their low
cost, ease of synthesis, and adjustable properties through the appropriate selection of
hydrogen bond donors and acceptors. In this study, the incorporation of protonated
caffeine into a DES was explored for the first time, leveraging its chemical structure to
enhance the stability and functionality of the system. Caffeine was protonated through an
optimized procedure in an anhydrous medium, preventing the presence of water, which
allowed for efficient interaction with hydrogen chloride. Characterization via TGA, FTIR,
and NMR confirmed the formation of the N-H bond in the imidazole ring, suggesting an
increased capacity for interaction with other DES components.
Various combinations of hydrogen bond acceptors and donors were evaluated to
determine the optimal composition of the system, revealing that the most stable and
functional mixture was obtained with ethylene glycol (HBD) and zinc chloride (HBA)
in a molar ratio of 2:1:0.1 (ETG:ZnCl2 :CafCl). Characterization through FTIR and NMR
confirmed the formation of hydrogen bonds and the coordinative interaction between the
components, verifying the structural stability of the system.
Computational simulations using COSMO-RS and ab initio molecular dynamics
(AIMD) enabled the analysis of charge distribution and hydrogen bond formation in
the eutectic mixture. The sigma profiles indicated that protonated caffeine possesses highly
polar regions capable of establishing strong interactions with ethylene glycol and ZnCl2 ,
enhancing the stability of the system. Additionally, radial distribution function (RDF)
analysis showed a reduction in the interaction distance between key atoms in the system
upon incorporating protonated caffeine, suggesting an improvement in DES stability.
This new DES exhibits great potential for industrial applications, particularly in the
extraction of sulfur compounds from fossil fuels, which could contribute to reducing
pollutant emissions. The inclusion of protonated caffeine in the eutectic mixture provides
additional advantages in terms of thermal stability and solvation capacity.
Although the ternary DES exhibits good thermal stability at 50 ◦ C, its viscosity increases significantly at lower temperatures, which may impact its potential applications.
Additionally, long-term stability remains a key concern. As shown in Figure 1, protonated
caffeine undergoes thermal degradation at temperatures above 70 ◦ C, potentially affecting
both the thermal and chemical stability of the DES under industrial conditions. To overcome
these limitations and enhance the industrial applicability of this DES, several strategies
can be considered. First, optimizing the synthesis conditions by exploring alternative
hydrogen bond donors or acceptors could help reduce viscosity at lower temperatures
while maintaining stability. Additionally, incorporating co-solvents or additives may improve fluidity without compromising the DES’s unique properties. To address long-term
stability concerns, process modifications such as maintaining operations within an optimal
temperature range should be explored. Furthermore, encapsulation techniques or the use of
protective atmospheres could minimize moisture absorption and thermal decomposition.
Author Contributions: L.S.B.-M.: investigation, formal analysis, writing—original draft, and methodology. M.F.T.-P.: investigation and methodology. L.M.O.-C.: supervision, methodology, project
administration, and funding acquisition. L.E.-V.: formal analysis, writing—original draft, visualization, and methodology. All authors have read and agreed to the published version of the manuscript.
Funding: The authors wish to express their profound gratitude to the project “Development of
Caffeine-Based Ionic Liquids for Fuel Desulfurization” (Hermes Code 54126) for its valuable support
in the development of this research.
Institutional Review Board Statement: Not applicable.
Molecules 2025, 1, 0
15 of 17
Informed Consent Statement: Not applicable.
Data Availability Statement: The original contributions presented in this study are included in the
article. Further inquiries can be directed to the corresponding author.
Acknowledgments: During the preparation of this manuscript, the authors used ChatGPT 4o for
grammatical correction of the document. The authors have reviewed and edited the output and take
full responsibility for the content of this publication.
Conflicts of Interest: The authors declare no conflicts of interest.
References
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
Clarke, C.J.; Tu, W.C.; Levers, O.; Bröhl, A.; Hallett, J.P. Green and Sustainable Solvents in Chemical Processes. Chem. Rev. 2018,
118, 747–800. [CrossRef] [PubMed]
Nanda, B.; Sailaja, M.; Mohapatra, P.; Pradhan, R.K.; Nanda, B.B. Green solvents: A suitable alternative for sustainable chemistry.
Mater. Today: Proc. 2021, 47, 1234–1240. [CrossRef]
Bains, W.; Petkowski, J.J.; Seager, S. Alternative Solvents for Life: Framework for Evaluation, Current Status and Future Research.
2022. Available online: https://arxiv.org/ftp/arxiv/papers/2401/2401.07296.pdf (accessed on 16 April 2024).
Armenta, S.; Esteve-Turrillas, F.A.; Garrigues, S.; de la Guardia, M. Alternative green solvents in sample preparation. Green Anal.
Chem. 2022, 1, 100007. [CrossRef]
Lomba, L.; García, C.B.; Ribate, M.P.; Giner, B.; Zuriaga, E. Applications of deep eutectic solvents related to health, synthesis, and
extraction of natural based chemicals. Appl. Sci. 2021, 11, 10156. [CrossRef]
Gurkan, B.E.; Maginn, E.J.; Pentzer, E.B. Deep eutectic solvents: A new class of versatile liquids. Am. Chem. Soc. 2020, 124,
11313–11315. [CrossRef]
Florindo, C.; Branco, L.C.; Marrucho, I.M. Quest for Green-Solvent Design: From Hydrophilic to Hydrophobic (Deep) Eutectic
Solvents. ChemSusChem 2019, 12, 1549–1559. [CrossRef]
Yang, Z. Natural Deep Eutectic Solvents and Their Applications in Biotechnology. In Advances in Biochemical Engineering/Biotechnology; Springer: Berlin/Heidelberg, Germany, 2019; Volume 168, pp. 31–59. [CrossRef]
Francisco, M.; Van Den Bruinhorst, A.; Kroon, M.C. Low-transition-temperature mixtures (LTTMs): A new generation of designer
solvents. Angew. Chem. Int. Ed. 2013, 52, 3074–3085. [CrossRef]
Bösmann, A.; Datsevich, L.; Jess, A.; Lauter, A.; Schmitz, C.; Wasserscheid, P. Deep desulfurization of diesel fuel by extraction
with ionic liquids. Chem. Commun. 2001, 23, 2494–2495. [CrossRef]
Kumar, A.A.P.; Banerjee, T. Thiophene separation with ionic liquids for desulphurization: A quantum chemical approach. Fluid
Phase Equilib 2009, 278, 1–8. [CrossRef]
Nie, Y.; Li, C.; Meng, H.; Wang, Z. N,N-dialkylimidazolium dialkylphosphate ionic liquids: Their extractive performance for
thiophene series compounds from fuel oils versus the length of alkyl group. Fuel Process. Technol. 2008, 89, 978–983. [CrossRef]
Ghandi, K. A Review of Ionic Liquids, Their Limits and Applications. Green Sustain. Chem. 2014, 4, 44–53. [CrossRef]
Lima, F.; Branco, L.C.; Silvestre, A.J.D.; Marrucho, I.M. Deep desulfurization of fuels: Are deep eutectic solvents the alternative
for ionic liquids? Fuel 2021, 293, 120297. [CrossRef]
United States Environmental Protection Agency. Control of Air Pollution from Motor Vehicles: Tier 3 Motor Vehicle Emission and
Fuel Standards. 2014. Available online: http://www.epa.gov/oar/ (accessed on 16 April 2024).
Gano, Z.S.; Mjalli, F.S.; Al-Wahaibi, T.; Al-Wahaibi, Y.; AlNashef, I.M. Extractive desulfurization of liquid fuel with FeCl3 -based
deep eutectic solvents: Experimental design and optimization by central-composite design. Chem. Eng. Process. Process Intensif.
2015, 93, 10–20. [CrossRef]
Gano, Z.S.; Mjalli, F.S.; Al-Wahaibi, T.; Al-Wahaibi, Y.; Alnashef, I.M. Solubility of thiophene and dibenzothiophene in anhydrous
FeCl3 - and ZnCl2 -based deep eutectic solvents. Ind. Eng. Chem. Res. 2014, 53, 6815–6823. [CrossRef]
Shu, C.; Sun, T. Extractive desulfurisation of gasoline with tetrabutyl ammonium chloride-based deep eutectic solvents. Sep. Sci.
Technol. 2016, 51, 1336–1343. [CrossRef]
Warrag, S.E.; Adeyemi, I.; Rodriguez, N.R.; Nashef, I.M.; van Sint Annal, M.; Kroon, M.C.; Peters, C.J. Effect of the Type of
Ammonium Salt on the Extractive Desulfurization of Fuels Using Deep Eutectic Solvents. J. Chem. Eng. Data 2018, 63, 1088–1095.
[CrossRef]
Thermo Fisher Scientific. Fisher Scientific. Available online: https://www.fishersci.es/shop/products/caffeine-99-thermoscientific/11438643#?keyword=caffeine (accessed on 8 January 2025).
Li, C.; Li, D.; Zou, S.; Li, Z.; Yin, J.; Wang, A.; Cui, Y.; Yao, Z.; Zhao, Q. Extraction desulfurization process of fuels with ammonium
based deep eutectic solvents. Green Chem. 2013, 15, 2793–2799. [CrossRef]
Molecules 2025, 1, 0
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
37.
38.
39.
40.
41.
42.
43.
44.
16 of 17
Verma, P.; Srivastava, A.; Srivastava, K.; Tandon, P.; Shimpi, M. Molecular Structure, Spectral Investigations, Hydrogen Bonding
Interactions and Reactivity-Property Relationship of Caffeine-Citric Acid Cocrystal by Experimental and DFT Approach. Front.
Chem. 2021, 9, 708538. [CrossRef]
Jones, R.R.; Hooper, D.C.; Zhang, L.; Wolverson, D.; Valev, V.K. Raman Techniques: Fundamentals and Frontiers; Springer: New York,
NY, USA, 2019. [CrossRef]
Abiya, A.; Ilakiya, A.; Hemalakshmi, S.; Ramesh, S. Obtaining and Investigate of Caffeine from Contrasting Tea Specimen
Using Liquid-Liquid Extraction. In Proceedings of the 2022 Conference on Chemical Analysis, Angkor Wat, Cambodia,
6–10 November 2022.
Salami, M.; Ezabadi, A. Synthesis of the nano-magnetic ionic liquid based on caffeine and its catalytic application in the synthesis
of xanthenes. In Research on Chemical Intermediates; Springer: Dordrecht, The Netherlands, 2020; Volume 46, pp. 4611–4626.
[CrossRef]
Hitachi High-Tech. Thermal Analysis of Caffeine. Available online: https://hha.hitachi-hightech.com/assets/uploads/assets/
uploads/documents/Thermal_Analysis_of_Caffeine.pdf (accessed on 20 January 2025).
Rajam, K.; Rajendran, S.; Banu, N.N. Effect of caffeine-Zn2+ system in preventing corrosion of carbon steel in well water. J. Chem.
2013, 2013, 521951. [CrossRef]
Butt, S.; Hasan, S.M.F.; Hassan, M.M.; Alkharfy, K.M.; Neau, S.H. Directly compressed rosuvastatin calcium tablets that offer
hydrotropic and micellar solubilization for improved dissolution rate and extent of drug release. Saudi Pharm. J. 2019, 27, 619–628.
[CrossRef]
Sitkowski, J.; Stefaniak, L.; Nicol, I.L.; Martin, M.L.; Martin, G.J.; Webb, G.A. Complete assignments of the 1 H, 13 C and 15 N NMR
spectra of caffeine. J. Magn. Reson. 1995, 51, 839–841. [CrossRef]
Colherinhas, G.; Ludwig, V.; da Costa Ludwig, Z.M. GIAO-NMR spectroscopy of the xanthine’s structures in water solution
using S-MC/QM methodology: An evaluation of the DFT-functionals’ efficiency. J. Mol. Liq. 2022, 347, 117955. [CrossRef]
Li, J.G.; Hu, Y.F.; Peng, X.M.; Zhang, X.M. Study of physicochemical properties of FeCl3 /[C4 mim][Cl] ionic liquids. J. Chem.
Thermodyn. 2016, 97, 277–281. [CrossRef]
Sharma, S. Raman study of ferric chloride hexahydrate and ferric chloride hexadeutrate in crystalline, molten, and glassy states.
J. Non-Cryst. Solids 1974, 15, 83–95. [CrossRef]
Li, Q.; Dong, Y.; Hammond, K.D.; Wan, C. Revealing the role of hydrogen bonding interactions and supramolecular complexes in
lignin dissolution by deep eutectic solvents. J. Mol. Liq. 2021, 344, 117779. [CrossRef]
Krasil’nikov, V.N.; Tyutyunnik, A.P.; Zhukov, V.P.; Baklanova, I.V.; Gyrdasova, O.I.; Chulkov, E.V. Zinc glycolate Zn(OCH2 CH2 O):
Synthesis and structure, spectral and optical properties, electronic structure and chemical bonding. J. Alloy. Compd. 2022, 924,
166320. [CrossRef]
Calado, M.S.; Branco, A.S.H.; Najdanovic-Visak, V.; Visak, Z.P. Solubility of high-value compounds in environmentally friendly
solvents-liquid poly(ethylene glycol) and ionic liquids: Experimental study and thermodynamic analysis. J. Chem. Thermodyn.
2014, 70, 154–159. [CrossRef]
Andrejević, T.P.; Warżajtis, B.; Glišić, B.Ð; Vojnovic, S.; Mojicevic, M.; Stevanović, N.L.; Nikodinovic-Runic, J.; Rychlewska, U.;
Djuran, M.I. Zinc(II) complexes with aromatic nitrogen-containing heterocycles as antifungal agents: Synergistic activity with
clinically used drug nystatin. J. Inorg. Biochem. 2020, 208, 111089. [CrossRef]
Tfaili, S.; Gobinet, C.; Josse, G.; Angiboust, J.F.; Baillet, A.; Manfait, M.; Piot, O. Vibrational spectroscopies for the analysis of
cutaneous permeation: Experimental limiting factors identified in the case of caffeine penetration. Anal. Bioanal. Chem. 2013, 405,
1325–1332. [CrossRef]
Zareef, M.; Hassan, M.M.; Arslan, M.; Ahmad, W.; Ali, S.; Ouyang, Q.; Li, H.; Wu, X.; Chen, Q. Rapid prediction of caffeine in tea
based on surface-enhanced Raman spectroscopy coupled multivariate calibration. Microchem. J. 2020, 159, 105431. [CrossRef]
Baranska, M.; Proniewicz, L.M. Raman mapping of caffeine alkaloid. Vib. Spectrosc. 2008, 48, 153–157. [CrossRef]
Yang, Q.; et al. Qualitative and Quantitative Analysis of Caffeine in Medicines by Terahertz Spectroscopy Using Machine Learning
Method. IEEE Access 2021, 9, 140008–140021. [CrossRef]
Kupenko, I.; Dubrovinsky, L.; Dmitriev, V.; Dubrovinskaia, N. In situ Raman spectroscopic study of the pressure induced
structural changes in ammonia borane. J. Chem. Phys. 2012, 137, 074506. [CrossRef]
Jahanbakhsh-Bonab, P.; Khoshnazar, Z.; Jahanbin Sardroodi, J.; Heidaryan, E. A computational probe into the physicochemical
properties of cyclodextrin-based deep eutectic solvents for extraction processes. Carbohydr. Polym. Technol. Appl. 2024, 8, 100596.
[CrossRef]
Ghareh Bagh, F.S.; Shahbaz, K.; Mjalli, F.S.; Hashim, M.A.; Alnashef, I.M. Zinc (II) Chloride-Based Deep Eutectic Solvents for
Application as Electrolytes: Preparation and Characterization. J. Mol. Liq. 2015, 204, 76–83. [CrossRef]
Abbott, A.P.; Barron, J.C.; Ryder, K.S.; Wilson, D. Eutectic-Based Ionic Liquids with Metal-Containing Anions and Cations.
Chem.–Eur. J. 2007, 13, 6495–6501. [CrossRef]
Molecules 2025, 1, 0
45.
46.
47.
48.
49.
50.
51.
52.
53.
54.
55.
56.
17 of 17
Jha, D.; Maheshwari, P.; Singh, Y.; Haider, M.B.; Kumar, R.; Balathanigaimani, M.S. A comparative review of extractive
desulfurization using designer solvents: Ionic liquids & deep eutectic solvents. J. Oil Gas Energy 2023, 110, 101313. [CrossRef]
Pye, C.C.; Ziegler, T.; van Lenthe, E.; Louwen, J.N. An implementation of the conductor-like screening model of solvation within
the Amsterdam density functional package—Part II. COSMO for real solvents. Can. J. Chem. 2009, 87, 790–797. [CrossRef]
Echeverry-Vargas, L.; Estrada, D.; Gutierrez, L. Molecular Dynamics Simulations of the Interactions between a Hydrolyzed
Polyacrylamide with the Face and Edge Surfaces of Molybdenite. Polymers 2022, 14, 3680. [CrossRef]
Lemaoui, T.; Darwish, A.; Hammoudi, N.; Hatab, F.; Attoui, A.; Alnashef, I.; Benguerba, Y. Prediction of Electrical Conductivity
of Deep Eutectic Solvents Using COSMO-RS Sigma Profiles as Molecular Descriptors: A Quantitative Structure-Property
Relationship Study. Ind. Eng. Chem. Res. 2020, 59, 13343–13354. [CrossRef]
Delley, B. An All-Electron Numerical Method for Solving the Local Density Functional for Polyatomic Molecules. J. Chem. Phys.
1990, 92, 508–517. [CrossRef]
Delley, B. From molecules to solids with the DMol3 approach. J. Chem. Phys. 2000, 113, 7756–7764. [CrossRef]
Becke, A.D. Density-functional thermochemistry. III. The role of exact exchange. J. Chem. Phys. 1993, 98, 5648–5652. [CrossRef]
Vosko, S.H.; Wilk, L.; Nusair, M. Accurate spin-dependent electron liquid correlation energies for local spin density calculations:
A critical analysis. Can. J. Phys. 1980, 58, 1200–1211. [CrossRef]
Mullins, E.; Oldland, R.; Liu, Y.A.; Wang, S.; Sandler, A.A.; Chen, C.C.; Zwolak, M.; Seavey, K. Sigma-profile database for using
COSMO-based thermodynamic methods. Ind. Eng. Chem. Res. 2006, 45, 4389–4415. [CrossRef]
Toikka, A.M.; Petrov, A.V. Comparative analysis of molecular interactions in quaternary fluid system performed by classical and
ab initio molecular dynamics. Mendeleev Commun. 2023, 33, 413–415. [CrossRef]
Becke, A.D. Density-functional exchange-energy approximation with correct asymptotic behavior. Phys. Rev. 1988, 38, 3098–3100.
[CrossRef]
Nosé, S. A molecular dynamics method for simulations in the canonical ensemble. Mol. Phys. 1984, 52, 255–268. [CrossRef]
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual
author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to
people or property resulting from any ideas, methods, instructions or products referred to in the content.
