Installation
4.5
Grounding
The 4590 TSM must be grounded to the tank potential before communication and power
connections are made. The connections (A ³ 4mm2) from each outer ground plug of the 4590
TSM to the tank ground must be made before any other wiring connections are made. All
grounding must be compliant with local and company regulations and checked before the
equipment is commissioned.
A > 4 mm2
Tank Ground
Figure 4-7:
Grounding Diagram
It is recommended to connect the cable shields of the tank instrumentation centrally to the 4590
TSM. See Section 5.2.3.3, "Grounding of the cable screen (for 7500 Series Radar Tank Gauges)"
on page 31 for more information.
4.6
Post-installation Check
After the 4590 TSM has been installed, perform the following checks:
• Is the measuring instrument damaged (visual check)?
• Have the mounting bolts been tightened securely?
• Are both grounding terminals connected to tank ground?
