www.daiwha.com www.daiwha.com DAIWHA Infusion Pump medifusion@mpMQPPP Infusion Pump SPECIFICATION p@n Volumetric Infusion Pump m MEDIFUSION p@s PERISTALTIC SEMI-TRANSIT FINGER f@r @r 0.1 to 99.9ml/h (in 0.1ml/h increments) MEDIFUSION MP-1000 MP-1000 High Performance & Easy Operation 100ml/h to 999ml/h (in 1m/h increments) a 5 % with assigned IV set v @d 0.1 to 9,999 ml p @f@r 700 ml/h (or selectable) v @l@r 0.1 to 9,999 ml a@F@i Air in line Infusion complete Occlusion (Up/Down) Empty container Low battery Door open Other device malfunctions f Keep-Vein -Open Drop sensor (Controls drip rate of IV sets and detect irregularities in drop count) Tubing Clamp Mechanism Broad Range of Delivery rate settings Volume Memorize Function Selectable One Shot Purge Easy replacement of Battery & convenent Battery indicator Free drop protection Finger User Selectable setup (IV set, sound, occlusion, etc) p @r AC 100 to 240V, 50/60hz, External 12V DC p @c Less than 30VA c Class I, Type BF, IPX 1 b @s Rechargeable Nickel-Metal Hybride Battery can run the pump continuously for about 3 hours at an operating rate of 25ml/h c Drip Proof a AC Power, Drop Sensor, IV Sets, Operation Guide d HI (D)166 X (W)258 X (H)125 w Approx 3.2 Kg Distributor: Head Quarter ; DAIWHA Bldg. 733-18, Yeoksam-Dong, Kangnam-Ku, Seoul, Korea Phone : 82-2-558-1711〜6 / Fax : 82-2-554-0317 Home Page : http://www.daiwha.com / E-mail : [email protected] Factory ; 177, Youngchun Ri, Dongtan Myun, Hwasung Si, Kyungki Do, Korea Phone: 82-31-376-9383~6 / Fax: 82-31-376-9387 Printed in Korea 2003 infusion@pump High Performance & Easy Operation www.daiwha.com medifusion@mpMQPPP ●Drop sensor Broad Range of Flow Rate Settings The flow rate can be set up to a maximum of 999ml/h, and can be adjusted in 0.1ml/h increments up to 99.9ml/h. ● Infused volume indicator ● Total volume indicator Improved Drop Sensor Safety Features The drop sensor controls flow rate of IV fluid, and detects irregularities in drop count. - A keep vein open (KVO) system that prevents the blood access from closing once the programmed infusion volume has been delivered. Convenient Battery Indicator Battery Replacement is Easy - A tube-clamping mechanism that automatically stops infusion when the door is inadvertently opened, and accidental power cutoff prevention that allows the pump to continue running even if the ON/OFF key is mistakenly pressed during infusion. - The MP-1000 has a drip-proof construction that protects it from infiltration by water or IV solution, and it complies with electromagnetic compatibility (EMC) standards. The batteries can be easily replaced simply by opening the battery cover at the bottom of the unit. Application ● Alarm indicator (Air, Occlusion, Door open, Low battery, Infusion complete) ● Volume display ● Up occlusion sensor ● Interworking part lever ● Flow rate display Compatible with Most IV Sets ● Purge indicator ● Stop indicator ● Infusion indicator in progress ● Interworking part ● Mode key The MP-1000 has a pre-programmed data for all kinds of standard IV sets. The operator can make it possible to use the pump with any standard IV sets without special trying and efforts. A 3-Level indicator displays the charging status and remaining capacity of the internal battery, so that the operator knows when to get spare batteries or switch over to AC power. ● Purge key ● Selection key ● Start key Memory Function ● Stop key ● Flow rate setting keys ● Down occlusion sensor When the power is turned off, the unit stores and retains the most recent flow rate, total volume. ● ON/OFF key ● Air sensor ● Power source indicator ● Battery indicator Variable Alarm Functions - Air in line - Occlusion - Door open - Low battery - Infusion complete - Empty container - Other device malfunction Clears EMC Standards The pump conforms to international standards for electromagnetic compatibility (EMC), which require that devices not be affected by electromagnetic fields from external sources and not emit electromagnetic waves sufficient to affect the operation of other electronic devices. - Continuous low flow rate infusion of fluid drug and transfusion in ICU or CCU - Continuous infusion of anesthetic, anticancer agent and nutrient to immature infant or newborn
