Proc. 2015 Canadian Engineering Education Association (CEEA15) Conf.
SHORT DESIGN PROJECTS FOR AN INTRODUCTORY THERMOFLUIDS ENGINEERING
COURSE
Michele Hastie* and Jan Haelssig
Department of Process Engineering and Applied Science
Dalhousie University, Halifax, NS B3H 4R2
*E-mail: [email protected]
Abstract – The Faculty of Engineering at Dalhousie
University offers a common introductory course that
covers the basic principles of thermodynamics and fluid
mechanics in a unified manner. This introductory course
is a mandatory part of the curriculum for all engineering
programs offered at Dalhousie. In this course, students
are required to perform six laboratory experiments, and
since 2012 students have also completed short, four-week
design projects.
The short design project helps students to acquire
more of the graduate attributes defined by the Canadian
Engineering Accreditation Board (CEAB), including
design, communication, and team work skills. They also
provide students with a well-deserved break from purely
theoretical work in lectures and tutorials, and a chance to
develop some hands-on abilities.
This paper describes the lessons learned from the last
three design projects, which were focused on
modifications to a Ranque-Hilsch vortex tube, design of a
pop-pop boat, and design of a double pipe heat
exchanger. The primary challenges have been the limited
engineering design experience possessed by students in
their third semester of studies, the heavy workload that
second-year engineering students already have, and the
relatively large class size. Even though there are clear
challenges related to integrating a design project into a
large second-year class, the results seem to indicate that
these design projects provide a positive learning
experience for the students.
Keywords: Thermofluids Engineering, Course-integrated
Design Projects, Double Pipe Heat Exchanger, Pop-pop
Boat, Ranque-Hilsch Vortex Tube.
1. INTRODUCTION
Introductory thermodynamics and fluid mechanics
courses are a normal part of core engineering curricula at
a large fraction of engineering schools across Canada. At
Dalhousie University, after an extensive review of the
CEEA15; Paper 053
McMaster University; May 31 – June 3, 2015
curriculum of the core engineering program, it was
decided to offer a common introductory course that covers
the basic principles of thermodynamics and fluid
mechanics in a unified manner. This introductory course is
part of the curriculum for all engineering programs
offered at Dalhousie (chemical, civil, electrical,
environmental, industrial, materials, mechanical, and
mineral resource engineering). The course was first
offered in the fall semester of 2011 and covers a wide
range of topics, including fluid statics, thermodynamic
properties of fluids, applications of the first and second
law to closed and open systems, and engineering
applications of the Bernoulli equation. Additionally,
students perform six laboratory experiments and, since
2012, a short, four-week design project. The last three
design projects were focused on modifications to a
Ranque-Hilsch vortex tube, design of a pop-pop boat, and
design of a double pipe heat exchanger.
The laboratory exercises, and the design project in
particular, help students to develop more of the graduate
attributes defined by the CEAB. These specific attributes
are design, communication and team work skills. The
additional advantage of incorporating small design
projects into several courses early in the curriculum is that
this creates more opportunities to track the development
of the attributes throughout the degree. This feedback
inherently provides more opportunities to improve the
curriculum.
There is evidence that most engineers are active
learners, meaning that they process information through
active experimentation rather than reflective observation
[1]. For a core course that largely consists of passive
learning through lectures, incorporating a short design
project can help reach out to students who are active
learners, which may be the majority of the class.
Experiments and design projects also allow students to
visualize the physical concepts that they are studying,
which generally helps to build a deeper foundational
understanding.
Other benefits of short design projects are that they
expose students to basic hand tools and construction
– 1 of 6 –
Proc. 2015 Canadian Engineering Education Association (CEEA15) Conf.
materials and introduce students to open-ended design
problems. These are some of the motivations described by
Davis [2], who incorporated a heat exchanger design
project into a core chemical engineering heat transfer
course at the University of Minnesota Duluth. Giving
students an opportunity to gain practical, hands-on
mechanical skills was in response to feedback from
industrial advisors who stated that students were lacking
these skills upon entering the work place.
Research on project-based learning methods have
found that they result in better performance on
assessments of conceptual understanding, improve the
ability to solve complex problems, and improve attitudes
towards learning [3]. Students are generally also more
motivated and demonstrate better communication and
teamwork skills.
There are several challenges related to running design
projects in a core engineering course. Students in their
third semester of engineering typically only have minimal
experience with the engineering design process, and
therefore it is necessary to be flexible in its application.
The large class size, typically 250 to 300 students at
Dalhousie, can make it difficult to schedule lab time and
to purchase an adequate amount of materials. Further,
second-year engineering students already tend to have a
relatively high workload, so it is important to make sure
that an additional course project will not overwhelm them.
Other challenges are related to the structure of the
project. If students are permitted to proceed without any
analysis or design planning, the student may not be
developing their conceptual thinking and design skills [4].
Failure of a group to achieve a successful prototype may
leave a lasting negative impression on the student.
Further, some students may struggle with self-directed
learning, so the success of the project depends on the level
of support and guidance provided by the instructor to help
the students learn how to learn on their own.
This paper presents a summary of our experiences with
implementing these short design projects over the past
three years. The course structure is summarized and the
past three design projects are described. The results from
these projects are then analyzed from a student experience
and pedagogical standpoint. The hope is that this paper
will provide useful information for other educators
interested in implementing short design projects in their
core engineering courses.
2. COURSE OVERVIEW
2.1. Structure and Objectives
Introductory thermodynamics and fluid mechanics
courses are typically taught separately. Since 2011 at
Dalhousie, introductory thermodynamics and fluid
CEEA15; Paper 053
McMaster University; May 31 – June 3, 2015
mechanics have been taught in a single third-semester
course to students in all engineering disciplines.
Obviously such a course cannot incorporate all of the
material that would be covered in separate introductory
courses, therefore students in disciplines requiring deeper
thermodynamics and/or fluid mechanics knowledge take
appropriate additional courses. However, the intention of
this first course is to provide students with a basis in both
of these important topics. A further objective in teaching
this material in an integrated manner is to permit students
to see the common first principles shared by these topics.
Examples of some of the connections that students
typically struggle to make are the link between the first
law of thermodynamics and the Bernoulli equation, and
the link between the second law of thermodynamics and
fluid friction.
The course has three lecture hours, three tutorial hours,
and two laboratory hours per week. Lectures are taught to
the entire group of students in an auditorium. Tutorials
and labs are taught in sections of 50 to 80 students. There
are typically six formal laboratory experiments, and one
four-week design project. There are typically no labs
during the two midterm exam weeks.
Over the last three years, the design projects have
involved a build and test component. We have normally
divided the class into groups consisting of four to six
students. The students are given the project description
and asked to reflect on the problem. They then have two
work periods (over two weeks) to plan and construct the
prototype. Testing is normally done during the third work
period. At this point groups normally have a sufficient
amount of results to write their report. However, to
provide some margin of error, a fourth work period is
normally available for additional testing a few days before
the report due date.
2.2. Course Projects
In developing specific design projects for the
thermofluids engineering course at Dalhousie, we have
usually relied on discussions with colleagues and brief
reviews of the engineering education literature to gather
ideas. The last three design projects are described below.
2.2.1. Ranque-Hilsch Vortex Tube Inserts (Fall 2012).
A Ranque-Hilsch vortex tube is a mechanical device that
produces hot and cold gas streams from a compressed gas
stream. These devices are commonly used in applications
where a supply of compressed air is readily available and
where local cooling is required. The efficiency of these
devices is considerably lower than for traditional air
conditioning or refrigeration systems. However, their
simplicity combined with the fact that they have no
moving parts makes them ideal for operation in harsh
environments.
– 2 of 6 –
Proc. 2015 Canadian Engineering Education Association (CEEA15) Conf.
In a typical vortex tube, compressed air enters a
chamber which induces the gas to rotate or spin. The
chamber usually contains a small metal or plastic insert
that directs the fluid and induces the optimal angle of fluid
rotation. This insert is commonly referred to as the
“Generator” or “Vortex Generator”. The ratio of the
flowrates of the hot and cold gas streams and their
temperature levels can normally be adjusted using a valve
on the hot air outlet.
The vortex tube is a relatively simple and affordable
way to demonstrate the basics of the first and second laws
of thermodynamics. Further, students must apply concepts
such as the ideal gas law, as well as mass, energy, and
entropy balances in the analysis of such a device [5]. The
results can also be used to estimate the coefficient of
performance (COP) by comparing the heat output of the
cold side to the energy consumed by the compressor [6].
For the project, a commercial vortex tube was
purchased from EXAIR® and tested by the students by
measuring inlet and outlet pressures and temperatures, and
outlet flowrates. The students were responsible to design
and build their own generators, and to test and compare
the results from their design to the commercial design.
Designs were drawn using Solid Edge 3D CAD software
and created using a 3D printer. The test station used to
make the measurements is shown in Fig. 1.
Hot air flow meter,
pressure gauge and
thermocouple
Cold air flow meter,
pressure gauge and
thermocouple
Inlet
thermocouple
Compressed air
inlet
Inlet pressure
gauge
Hot/cold air
control valve
Fig. 1. Vortex tube test station.
2.2.2. Pop-pop Boats (Fall 2013). A pop-pop (also called
putt-putt) boat is a toy boat powered by a simple steam
engine without any moving parts. The steam engine
usually consists of two or more tubes protruding from the
rear of the boat. On the other end, the tubes are attached
to a reservoir. This reservoir is normally either a separate
space or the tubes themselves arranged in a coil. During
operation, a heat source (e.g., a candle) supplies heat to
the reservoir, causing some of the water to vaporize. The
generated steam expands and expels water present in the
tubes. This expulsion of water provides forward motion to
the boat. Once the expanding steam reaches the cooler
CEEA15; Paper 053
McMaster University; May 31 – June 3, 2015
section of the tube, it condenses. Eventually enough steam
condenses to generate a low pressure in the reservoir, and
as a result water flows into the ends of the tubes. This
cycle is then repeated as long as heat is supplied to the
system. The overall mechanism is similar to that in a
pulsejet engine.
Although typically only used as a toy, the pop-pop boat
provides an interesting way to demonstrate some key
topics in thermofluids, such as the use of steam to
generate work, the changing properties of fluids
throughout a power cycle, the second law of
thermodynamics, and propulsion. Detailed discussions of
the operating principles behind the pop-pop boat can be
found in many sources [7-9].
To build their pop-pop boat, students were supplied
with one 12-inch by 12-inch sheet of aluminum, one 12inch by 24-inch sheet of aluminum, one 48-inch length of
1/8” OD copper tubing, one 48-inch length of 3/16” OD
copper tubing, five straws, one 1-ounce tube of epoxy,
two tealights (candles), one half-pound bag of paraffin
wax beads for making candle(s), and candle wick.
Additionally, students could use empty pop cans and/or
pop bottles. To construct the boats, the students had
access to typical hand tools and a drill press.
The performance of the boats was determined by
measuring both speed and thrust. The speed was measured
by timing how long it took to complete a lap in the project
race track (i.e., an 80-inch diameter blow-up pool). The
thrust was measured by using a small spring scale. Using
the thrust and the average speed, a rough estimate of the
power output by the engine was obtained and used to
estimate the efficiency of the engine. Students were
expected to submit a CAD drawing of their final boat
design, along with the completed prototype.
2.2.3. Double Pipe Heat Exchangers (Fall 2014). The
heat exchanger project was based on the project described
and implemented by Davis [2], which was also used as
inspiration for a similar project in the biotechnology
program at Dublin City University [10]. Heat exchangers
are essential in many process industries. While there a
many configurations of heat exchangers depending on the
application and the fluids involved, the simplest version of
a heat exchanger is the double-pipe heat exchanger. A
prototype can be made from copper and PVC (polyvinyl
chloride) pipe. A hot fluid (e.g., hot tap water) flows
through the copper tubing on the inside of the heat
exchanger, while a cold fluid (e.g., cold tap water) flows
through the PVC pipe surrounding the copper tubing. As
the fluids flow through the exchanger, heat is transferred
from the hot to the cold fluid. By measuring the flow rates
and change of temperatures for both hot and cold streams,
the heat transferred from the hot stream to the cold stream
can be determined through an open system, steady-state
energy balance.
– 3 of 6 –
Proc. 2015 Canadian Engineering Education Association (CEEA15) Conf.
To build their double pipe (or shell and coil) heat
exchangers, students were supplied with one 1-foot length
of 2” PVC pipe, one 6-foot length of 3/16” OD copper
tubing, and enough connections and fittings to be able to
connect to the test station. Additionally, students had
access to PVC pipe glue (primer and cement), Teflon®
tape, and some other odds-and-ends in the lab. They also
had access to typical hand tools in the lab.
The primary design component of the project was in
choosing how to arrange the copper tubing inside the PVC
pipe, with the two most popular designs being a coil and a
multi-pass tube arrangement. After construction, the heat
exchangers were tested and the students applied the
steady-state energy balance equation to calculate the rate
at which heat was released by the hot fluid and absorbed
by the cold fluid, and explain any discrepancy between the
two values. Also, comparisons between different designs
could be made to determine the best arrangement for the
copper tubing.
The test station used to make measurements for the
project is shown in Fig. 2. The temperatures were
measured at the inlet and outlet for both streams. The flow
rates of both the hot and cold streams were also measured.
Students were expected to submit a CAD drawing of their
final heat exchanger, along with the completed prototype.
Cold water
flow direction
Hot water thermocouples
(outlet – left, inlet – right)
Temperature
display
Cold water inlet,
flowmeter,
thermocouples,
and outlet on other
side of apparatus
Hot water flowmeter
Fig. 2. Heat exchanger test station.
3. RESULTS AND DISCUSSIONS
3.1. Project Quality
Figure 3 shows the sample vortex tube insert that we
showed the students at the beginning of the vortex tube
project to give them a basis for their designs. The sample
design was purposely inefficient, so that there was
significant room for improvement. We also explained to
the students that the 3D printer had a certain tolerance,
and that approaching this tolerance too closely might lead
to structural failure.
Inevitably, some students did print designs that were
too complicated to be accurately replicated by the 3D
printer, and ultimately these designs did not work very
well. However, many students did synthesize designs that
were more efficient than the sample. Examples of two of
these designs are shown in Fig. 4. These designs primarily
CEEA15; Paper 053
McMaster University; May 31 – June 3, 2015
Fig. 3. Sample vortex generator.
Fig. 4. Examples of student vortex generator designs.
Hot water
flow direction
Air relief
valve
improved upon the sample because they provide space for
air to evenly distribute before entering the generator.
Other designs investigated the trajectories of the vanes
and various gap sizes. There were also various unique
designs incorporating a strategically placed hole, but
many of these did not work very well due to the resolution
of the 3D printer.
Figure 5 shows one of the two sample pop-pop boats
that we showed the students at the beginning of the boat
design project. We made it clear to the students that these
designs were based on a very brief literature review, and
that they were by no means optimized. We encouraged the
students to perform their own comprehensive literature
review and base their design on logical arguments and
some small calculations. We warned them that it would be
relatively difficult to build very complex hull designs with
the hand tools that were available. Additionally, we
warned the students to make sure that their boats would be
stable when placed in water.
In the end, most students built relatively simple hull
designs and focused their efforts on making candles and
efficient boilers. Many groups started by constructing two
prototypes and then eliminated one of these when they
realized that one performed significantly better than the
other. There were many unique single-coil and double-coil
copper tube boiler designs with varying sizes.
Additionally, some groups constructed boiler reservoirs
using pop cans. Eventually most groups realized that the
performance of their boat could be improved by
maximizing the amount of heat transferred to the boiler.
Therefore most groups focused their final design iterations
on maximizing the surface area of the boiler and changing
the candle size and location. Two example boat designs
are shown in Fig. 6.
– 4 of 6 –
Proc. 2015 Canadian Engineering Education Association (CEEA15) Conf.
a)
b)
c)
d)
Fig. 5. Sample pop-pop boat.
e)
f)
Fig. 8. Examples of student heat exchanger designs: a)
standard coil design, b) multi-pass design, c) serpentine
design, d) combined coil and multi-pass design, e) coil
with changing diameter, f) CAD drawing.
Fig. 6. Examples of two student pop-pop boat designs:
CAD drawing (left) and completed prototype (right).
Similar to the sample vortex tube insert and pop-pop
boat, the sample heat exchanger, shown in Fig. 7, did not
use the most creative or best design with regards to the
use of copper tubing. The copper tubing ran straightthrough the PVC pipe, minimizing the available heat
transfer area. The use of clear PVC pipe, while too
expensive to use for all of the projects, effectively
displayed the inner workings of the heat exchanger.
Fig. 7. Sample heat exchanger.
The students were encouraged to develop a more
creative arrangement of the copper tubing within the PVC
pipe, and some examples are shown in Fig. 8. We
recommended that they included the full length of copper
tubing inside the PVC pipe to maximize heat transfer area.
The secondary goal was to arrange the tubing such that it
created turbulence in the water flowing on the outside of
the copper tubing. The simplest designs were the standard
coil (Fig. 8a) or a multi-pass arrangement (Fig. 8b). More
creative designs incorporated both coil and multi-pass
aspects (Fig. 8c and d) or improved on the standard coil
by using changing diameters to promote turbulence
(Fig. 8e). Fig. 8f shows an example of a group’s
completed CAD drawing.
CEEA15; Paper 053
McMaster University; May 31 – June 3, 2015
3.2. Analysis and Student Feedback
In all three years, the students displayed a high level of
enthusiasm toward the design project. This was especially
evident for the students who either had previous
experience with build projects or who had a keen interest
in developing these skills. The projects gave students who
already had strong hands-on skills an opportunity to excel
and even teach their less experienced classmates.
Although a few students brought these skills to the
project, it was also evident that most students had a
minimal amount of hands-on practical skills at this stage
in their education. Specific skills obtained from the vortex
tube project (Fall 2012) include learning how to use 3D
printers, how to fasten compression fittings, and how to
read rotameters and pressure gauges. Specific skills
obtained from the pop-pop boat project (Fall 2013)
include learning how to work with copper tubing and
sheet metal and how to apply epoxy. Specific skills
obtained from the heat exchanger project (Fall 2014)
include learning how to fasten compression fittings,
connect PVC pipe, apply epoxy and Teflon® tape, and
read rotameters. Additionally all three of these projects
exposed the students to some basic hand tools. Though
these skills seem trivial to experienced engineers and
technicians, most early year engineering students have
never been exposed to them before. Having even minimal
experience will improve confidence and put them in a
better position to be productive as junior engineers.
Whether the students’ understanding of the core
concepts involved in the project improved as a result of
the project is difficult to measure. Clearly, connections
– 5 of 6 –
Proc. 2015 Canadian Engineering Education Association (CEEA15) Conf.
between the project and the course material must be made
when writing the report, but it cannot be guaranteed that
all students will benefit equally from this aspect of the
project. It is therefore the instructor’s responsibility to
help make these connections by incorporating the project
into lectures and giving clear instructions about how to
apply calculations from the course to the project.
In general, students gave positive comments while
working on the projects. Only a few formal comments
were given in the end of year course evaluations. In 2014,
one student mentioned that they thoroughly enjoyed the
project. Another commented that the concepts needed to
analyze the heat exchanger design were beyond the scope
of the course. Although this may be true, it can be argued
that the foundational knowledge gained from the project
will be helpful to the students who will study heat
exchangers in greater detail in future heat transfer courses.
Further, it is relatively easy to challenge such an argument
because even practicing engineers rarely know every
detail about all related topics when confronted with a new
design problem.
Another negative comment was that there was not
enough room for creative design in the heat exchanger
project. This highlights a challenge in developing short
design projects: they must be open-ended enough to
encourage student creativity and effectively apply design
principles, yet constrained enough so that it is still
possible to come up with a working prototype within a
short period of time. From our experience, short design
projects such as this must be relatively well constrained
with students only focusing on specific aspects of the
design. Leaving the project too open-ended can lead to
frustration and cause some students to turn too much focus
away from the core course material. Keeping the project
constrained gives the students an achievable goal and
allows them to fully benefit from the experience.
4. CONCLUSIONS
In general, incorporating short design projects into the
introductory thermofluids course at Dalhousie has been a
positive experience. The major challenge is managing the
additional time and resources required to develop and run
the project. Project development, part sourcing, and
prototype building and testing should be done during a
prior semester to avoid last minute stresses during the
semester.
If much of the project can be prepared ahead of time,
undertaking short design projects can be rewarding for
both the students and the instructors. The benefits include
reaching out to students whose learning styles do not
correspond well to traditional teaching methods, giving
the students exposure to basic hand tools and construction
materials, and developing their design and teamwork
skills.
CEEA15; Paper 053
McMaster University; May 31 – June 3, 2015
Acknowledgements
Financial support from Dalhousie’s Faculty of
Engineering and the Shell Experiential Learning Fund
(SELF) is gratefully acknowledged. Helpful advice from
Dr. Michael Pegg and Dr. Clifton Johnston is also
gratefully acknowledged. We would also like to thank the
students of ENGI 2102 from fall 2012, 2013 and 2014 for
their participation in the design projects and useful
feedback.
References
[1] Richard M. Felder and Linda K. Silverman, “Learning and
Teaching Styles in Engineering Education,” Engr.
Education, vol. 78, no. 7, pp. 674-681, 1988.
[2] Richard A. Davis, “A Project to Design and Build Compact
Heat Exchangers,” Chem. Eng. Educ., vol. 39, no. 1, pp. 3841, Winter 2005.
[3] Michael J. Prince and Richard M. Felder, “Inductive
Teaching and Learning Methods: Definitions, Comparisons,
and Research Bases,” J. Engr. Education, vol. 95, no. 2, pp.
123-138, 2006.
[4] Andrew Samuel, Make and Test Projects in Engineering
Design. London: Springer-Verlag, 2006, 47 pp. {ISBN
1852339152}
[5] Edorta Carrascal and José M. Sala, “Mass, energy, entropy
and exergy rate balance in a Ranque-Hilsch vortex tube,”
Journal of Technology and Science Education, vol. 3, no. 3,
pp. 122-131, 2013.
[6] Don Van, Joel Ingram, Kenneth Mayo, and Kian Jost,
“Process Analyzing of the Vortex Tube and The Teaching
and Learning of Energy Efficiency and Sustainability,” in
ASEE American Society of Engineering Education
Southeast Section Conf., (Cookeville, TN; 10-13 March
2013), 2013.
[7] Jeff Bindon, “The Secret Workings of a Transparent PopPop Engine,” Model Engineer, vol. 39, no. 1, pp. 38-41,
Winter 2005.
[8] V Sharadha and Jaywant H Arakeri, “Propulsion of the
Putt-Putt Boat – I,” Resonance, vol. 9, no. 6, pp. 66-73,
2004.
[9] V Sharadha, “Propulsion of the Putt-Putt Boat – 2,”
Resonance, vol. 9, no. 7, pp. 64-69, 2004.
[10] Brian Freeland, John M. Tobin, and Greg Foley, “A
Project and Competition to Design and Build a Simple Heat
Exchanger,” in Proc. of the International Symposium for
Engineering Education, ISEE-07, Dermot Brabazon and
Abdul-Ghani Olabi (eds.) (Dublin, Ireland; 2007), pp. 201206, 2007.
– 6 of 6 –
Descargar
