Configure your Router WIFI Tenda W136R as an access

Configure your Router WIFI
Tenda W136R
as an access point
1 ) Dejamos TODO con los valores de fábrica. (normalmente
cuando se hace correctamente este proceso, las luces del router
cambian a la vez):
- Fijarse lo que estaba conectado para dejarlo al final igual.
- Tiene que desconectar el cable de la conexion de internet.
- Antes de proceder a configurar el router, hay que asegurarse que SOLO hay 1 cable
conectado al router WIFI hasta el ordenador desde el cual se va a configurar.
When you correctly perform this
process, all router lights flash at
same time
This is WAN PORT
NEVER PLUG
ANYTHING
These are “LAN”ports, you can plug
any device you want
1
First press RESET button
for about 10-15 seconds.
2
2 ) Nex step is accessing to the router:
- Computer must be configured to wired network connection with automatic
IP address through DHCP (as seen on our website's tutorials).
-We'll open an internet browser and we'll write this address in the address bar:
“http://192.168.0.1/“.
- To access the router, the user for login is 'admin' and the password is 'admin'
- Then press OK
1
2
3
4
2.1) Then we click in Advanced to access the advanced settings.
1
3) Now we're going to set up Wireless settings
- Check that Wireless is enabled.
- SSID is the name of your Wifi name (NOT the password).
- Then press “OK” to save.
1
2
3
4
3.1) On the “Wireless security” tab
- Disable WPS option.
- Press “OK” to save.
1
2
3
3.2) This windows should appear. For higher security we will set:
- Security Mode: Mixed WPA/WPA2 – PSK,
- WPA Algorithms: TKIP&AES,
- Security Key: [Your password] (At least 8 characters)
- Press “OK” to save.
1
3
2
4
5
6
4) UPnP:
- UPnP keep it as disabled.
- Press “OK” to save.
1
3
2
4
4) Move back to “Advanced” tab an then to DHCP Server option
- Keep “DHCP SERVER” disabled.
- Press “OK” to save.
1
3
2
4
4) Finally on LAN Settings, we have to introduce these parameters:
- IP Address=192.168.1.2
- Subnet Mask=255.255.255.0
- Press “OK” to save.
1
3
2
4
5
5) Finally you have to plug EVERYTHING in it's original position
